Terex Man Lifts West Valley City

Terex Manlift Specifications

Terex is a Westport, Connecticut company that specializes in producing in manufacturing construction equipment. machinery like aerial lifts, manlifts and boom lifts. These machinery are designed to facilitate access to areas that are difficult to reach, large equipment, roofs and buildings, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt moves only in one direction and contains handholds or platforms or steps that are attached to the unit to be able to transport employees from each floor.



TB85

The TB85 man lift by Terex provides a max working height at 91 feet. The platform's max height reaches 85 feet, whilst the model's maximum width is 8.5 feet. The TB85 has dimensions that measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This model offers a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.



Terex TB100

The Terex TB100 man lift's maximum height is 106 feet and the platform's maximum height is 100 feet. The TB100 when stowed away, is approximately 8.5 feet wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.



TB110

The Terex TB110 man lift reaches a max height of 100 feet, while the max working height reaches 116 feet. The model is 8 feet wide x 9 feet, 4 inches high The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
